RT-AC68U
Features
AC1900 Dual Band Gigabit WiFi Router with MU-MIMO, AiMesh for mesh wifi system, AiProtection network security powered by Trend Micro, Adaptive QoS and Parental Control
- Great Wi-Fi – Enjoy the combined dual-band speeds of up to 1900Mbps, 3X faster than 802.11n routers
- Ultrawide Coverage – High-performance antennas and ASUS AiRadar eliminate dead spots
- Commercial-grade Security – AiProtection, powered by Trend Micro™, blocks and neutralizes internet security threats for all your connected smart devices
- AiMesh Supported – Connect your RT-AC68U to other compatible ASUS routers to create a powerful and flexible whole-home Wi-Fi network
- Flexible Connectivity Options– 5X Gigabit Ethernet ports, 1X ultrafast USB 3.1 port and 1X USB 2.0 port
Specifications
| Network Standard | IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IPv4, IPv6 |
| Product Segment | AC1900 ultimate AC performance : 600+1300 Mbps |
| Coverage | Large homes |
| Data Rate | 802.11n : up to 450 Mbps 802.11n TurboQAM : up to 600 Mbps 802.11ac : up to 1300 Mbps |
| Antenna | External antenna x 3 |
| Transmit/Receive | MIMO technology 2.4 GHz 3 x 3 5 GHz-1 3 x 3 |
| Memory | 128 MB Flash 256 MB RAM |
| Operating Frequency | 2.4 GHz / 5 GHz |
| Encryption | 64-bit WEP, 128-bit WEP, WPA2-PSK, WPA-PSK, WPA-Enterprise , WPA2-Enterprise , WPS support |
| Firewall & Access Control | Firewall：SPI intrusion detection,DoS protection Access control：Parental control, Network service filter, URL filter, Port filter |
| Management | UPnP, IGMP v1/v2/v3, DNS Proxy, DHCP, NTP Client, DDNS, Port Trigger, Universal Repeater, System Event Log |
| WAN Connection Type | Internet connection type : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP, L2TP WAN Bridge support Multicast Proxy support Multicast Rate Setting support |
| Ports | RJ45 for 10/100/1000/Gigabits BaseT for LAN x 4, RJ45 for 10/100/1000/Gigabits BaseT for WAN x 1 USB 2.0 x 1 USB 3.0 x 1 |
| Button | WPS Button, Reset Button, Power Button, Wireless on/off Button |
| Features | Airtime Fairness Adaptive QoS AiProtection Parental Control Guest Network : 2.4 GHz x 3, 5 GHz x 3 VPN server : IPSec Pass-Through, PPTP Pass-Through, L2TP Pass-Through, PPTP Server, OpenVPN Server VPN client : PPTP client, L2TP client, OpenVPN client Mac OS Backup Enhanced media server (AiPlayer app compatible) – Image : Jpeg – Audio : mp3, wma, wav, pcm, mp4, lpcm, ogg – Video : asf, avi, divx, mpeg, mpg, ts, vob, wmv, mkv, mov AiCloud personal cloud service 3G/4G data sharing Printer Server – Multifunctional printer support (Windows only) – LPR protocol support Download Master – Support bt, nzb, http, ed2k – Support encryption, DHT, PEX and magnet link – Upload and download bandwidth control – Download scheduling AiDisk file server – Samba and FTP server with account management Dual WAN IPTV support Roaming Assist |
| LED Indicator | Power x 1 Wi-Fi x 2 LAN x 4 WAN x 1 USB x 2 |
| Power Supply | AC Input : 110V~240V(50~60Hz) DC Output : 19 V with max. 1.75 A current |
| OS Support | Windows® 10 Windows® 8.1 Windows® 8 Windows® 7 Windows® Vista Windows® 2000 Windows® ME Windows® XP Windows® Server 2003 Windows® Server 2008 Mac OS X 10.1 Mac OS X 10.4 Mac OS X 10.5 Mac OS X 10.6 Mac OS X 10.7 Mac OS X 10.8 Mac OS X Linux Kernel (Support Ubuntu only) Linux |
| Dimensions | 220 x 83.3 x 160 ~ mm (WxDxH) (Without Bezel) |
| Package Content | 1 x RT-AC68U Wireless-AC1900 Dual Band Gigabit Router 1 x RJ-45 cable 1 x Power adapter 1 x QSG 1 x Support CD(user manual and ultility) |
| Operation mode | Wireless router mode Range extender mode Access point mode Media bridge mode |
| Warranty | 3 Years |
