Nvidia Quadro RTX A2000 6GB GDDR6 192-bit Workstation Graphics Card
Accelerate Your Workflow
The Nvidia Quadro RTX A2000 6GB brings the power of NVIDIA RTX technology, realtime ray tracing, AI-accelerated compute, and high-performance graphics to more professionals.
Built on the NVIDIA Ampere architecture, the VR ready RTX A2000 combines 26 second-generation RT Cores, 104 thirdgeneration Tensor Cores, and 3,328 next-generation CUDA® cores and 6GB of GDDR6 graphics memory with error correction code (ECC) support for error free computing.
The Nvidia Quadro RTX A2000 6GB features a power-efficient low profile, dual-slot PCIe form factor that fits into a wide range of small form factor workstations.
Design bigger, render faster, and work smarter than ever before with the Nvidia Quadro RTX A2000 6GB. NVIDIA RTX professional graphics cards are certified with a broad range of professional applications, tested by leading independent software vendors (ISVs) and workstation manufacturers, and backed by a global team of support specialists.
Get the peace of mind needed to focus on what matters with the premier visual computing solution for mission-critical business.
POWERED BY THE NVIDIA AMPERE ARCHITECTURE
NVIDIA Ampere Architecture-Based CUDA Cores
Accelerate graphics workflows with the latest CUDA® cores for up to 2X single-precision floating-point (FP32) performance compared to the previous generation.
NVIDIA RTX Ray Tracing Second-Generation RT Cores
Produce more visually accurate renders faster with hardware-accelerated motion blur and up to 2X faster ray-tracing performance than the previous generation.
NVIDIA DLSS Third-Generation Tensor Cores
Boost AI-augmented application performance, bringing advanced capabilities like AI denoising, DLSS, and more to graphics workflows.
Nvidia Quadro RTX A2000 6GB of GPU Memory
Drive graphics and compute-intensive workflows with 6 or 12 GB of GDDR6 memory with ECC, the first time ECC memory has been available in this GPU class.
Low-Profile, Dual-Slot Form Factor
Leverage a power-efficient design that fits into a wide range of workstation chassis.
PCI Express Gen 4
Improve data-transfer speeds from CPU memory for data-intensive tasks with support for PCI Express Gen 4.
Features
- PCI Express Gen 4
- Four DisplayPort 1.4a connectors with latching mechanism
- AV1 decode support
- DisplayPort with audio
- NVIDIA GPUDirect® for Video support
- NVIDIA RTX Experience™
- NVIDIA RTX Desktop Manager software
- HDCP 2.2 support
- NVIDIA Mosaic technology
Specifications :
| GPU Memory | 6 GB GDDR6 |
| Memory Interface | 192-bit |
| Memory Bandwidth | 228 GB/s |
| Error-correcting code (ECC) | Yes |
| NVIDIA Ampere architecture-based CUDA Cores | 3328 |
| NVIDIA third-generation Tensor Cores | 104 |
| NVIDIA second-generation RT Cores | 26 |
| Single-Precision Performance | 8.0 TFLOPS |
| RT Core Performance | 15.6 TFLOPS |
| Tensor Performance | 63.9 TFLOPS |
| System Interface | PCI Express 4.0 x16 |
| Power Consumption | Total board power: 70 W |
| Thermal Solution | Active |
| Form Factor | 2.7” H x 6.6” L, dual slot |
| Display Connectors | 4x mDP 1.4a with latching mechanism |
| Max Simultaneous Displays | 4x 4096 x 2160 @ 120 Hz, 4x 5120 x 2880 @ 60 Hz 2x 7680 x 4320 @ 60 Hz |
| Encode/decode engines | 1x encode, 1x decode (+AV1 decode) |
| VR Ready | Yes |
| Graphics APIs | DirectX 12.07 Shader Model 5.17 OpenGL 4.68 Vulkan 1.2 |
| Compute APIs | CUDA, DirectCompute, OpenCL™ |
| Warranty | 3 Year |
