Specification
| Specifications | 6 TB |
| Standard Model Numbers | ST6000VN0033 |
| Interface | SATA 6Gb/sc |
| Features and Performance | |
| Drive Bays Supported | 1 – 8 Bays |
| Multi-User Technology | 180 TB/year |
| Rotational Vibration (RV) Sensor | Yes |
| Dual-Plane Balance | Yes |
| Error Recovery Control | Yes |
| Max. Sustained Transfer Rate OD (MB/s) | 210MB/s |
| Spindle Speed (RPM) | 7,200 |
| Cache (MB) | 256 |
| Reliability | |
| Load/Unload Cycles | 600,000 |
| Non-recoverable Read Errors Rate, Max | 1 per 10E15 |
| Power-on Hours | 8,760 |
| Workload Rate Limit (WRL) | 180 |
| Mean Time Between Failures (MTBF, hours) | 1,000,000 |
| Power Management | |
| Startup Current, Typical (12V, A) | 1.8 |
| Average Operating Power (W) | 8.1 W |
| Idling Average (W) | 7.2 W |
| Standby Mode/Sleep Mode, Typical (W) | 0.6/0.6 |
| Voltage Tolerance, Inc. Noise (5 V) | ±5% |
| Voltage Tolerance, Inc. Noise (12 V) | ±10% |
| Environmental/Temperature | |
| Operating (ambient, min °C) | 5 |
| Operating (drive case, max °C) | 70 |
| Non-operating (ambient, min °C) | -40 |
| Non-operating (ambient max °C) | 70 |
| Halogen-free | Yes |
| Environmental/Shock | |
| Shock, Operating/Non-operating: 2 ms (max) | 70Gs/250Gs |
| Environmental/Acoustics | |
| Idle (typical) | 2.7 bels |
| Seek (typical) | 2.8 bels |
| Physical | |
| Height (mm/in) | 26.11 mm/1.028 in |
| Width (mm/in, max) | 101.85 mm/4.01 in |
| Depth (mm/in, max) | 146.99 mm/5.787 in |
| Weight (g/lb, typical) | 705 g/1.55 lb |
| Carton Unit Quantity | 20 |
| Cartons per Pallet / Cartons per Layer | 40/8 |
| Warranty | 3 Years |
Optimised for NAS with AgileArray.
AgileArray enables dual-plane balancing and RAID optimisation in multi-bay environments, with the most advanced power management possible.
Actively protect your NAS with IronWolf Health Management
focusing on prevention, intervention, and recovery.
High performance means no lag time
downtime for users during workload traffic for the NAS. Seagate leads the competition with the highest-performing NAS drive portfolio.
Rotational Vibration (RV) sensors.
First in its class of drives to include RV sensors to maintain high performance in multi-drive NAS enclosures.
Range of capacities up to 14 TB.
More capacity options means more choices that will fit within the budget. Seagate provides a scalable solution for any NAS use-case scenario.
Do more in multi-user environments.
IronWolf provides a workload rate of 180 TB/year. Multiple users can confidently upload and download data to the NAS server, knowing IronWolf can handle the workload, whether you are a creative professionalor a small business.
Designed for always-on, always-accessible 24×7 performance. Access data on your NAS any time, remotely or on site.
